ULTIMATE DEFENCE
Informative LCD display
Provides backup power – prevents data loss
Protects your sensitive and valuable equipment
Compact and reliable – ideal for home and small office use

Neprekidno napajanje za racunare od 1500 VA
Automatska regulacija izlaznog napona (AVR)
USB interfejs
LCD indikacija statusa
Zaštita od kratkog spoja
Zaštita od prenapona, šiljaka i groma
Zvucni i vizuelni alarmi
Zaštita od prekomernog punjenja i prekomernog pražnjenja
Ukljucujuci prakticni softver za upravljanje UPS-om

Type: line interactive
Waveform: sine wave (AC mains), modified (square) sine wave (battery)
Input: 220 V AC ± 25%, 50 / 60 Hz ± 10%
Output: 220 V AC ± 10%, 50 / 60 Hz ± 1% (220 V AC ± 5 % at inverter mode)
Switching time: less than 10 ms
Backup time: 8…20 mins (depends on the load)
Battery: sealed lead-acid 12 V DC / 8 Ah x 2 pcs(connected in series)
Charge time: up to 12 hours
Sockets: 1 x C14 input, 3 pcs x C13 output, 2 pcs x german Shuko
USB control interface: BF socket
Operating conditions: 0°C ~ 40°C, at humidity 20 ~ 90 %RH non condensing
Power: 1500 VA (900 W)
Charging current: up to 1.2 A
Noise: < 45 dB at 1 m distance
Dimensions: 400 x 125 x 220 mm
Net weight: 10.8 kg
“Cold-start” function

Softver je kompatibilan sa Windows Vista/7/8/2008 serverom
Da bi ispravno radio, prikljuceno opterec´enje treba da bude najmanje 5% maksimalnog kapaciteta UPS-a. Na primer, UPS-u od 700W je potrebno najmanje povezano opterecenje od 35W da bi radio.

ups mustek apc

24 meseca na uredjaj i 12 meseci na baterije

Manufacturer : Gembird – Scorpion Series
Model: GMB-600 PRO
Power: 600W 80+ BRONZE , CE/TuV/ ROHS
Format: ATX V2.31 and EPS SINGLE-RAIL
– Active PFC
– Energy efficiency 80+ BRONZE : 82%, 85%, 82% at 20%, 50%, 100% load
– Red color 12cm ball bearing Fan temperature controlled for low-noise performance. MTBF: 100,000 h
– Protection: OVP/ UVP/ OPP/ SCP (Over Voltage Protection, Under Voltage Protection, Over Power Protection, Short Circuit Protection)
– 100% burn-in/vibration/Hi Pot/Leakage current Test.
– Incl. 1.2m EU power cord
– Input socket +I/O
– On/Off Switch
– Cable length: all > 50cm.
Dimension: 150x140x85mm

– Connectors, cables all with BLACK MESH :
1x MB ATX 12V 20+4 Pin (50cm)
1x CPU ATX12V 4+4 Pin (55cm)
2x PCI-E 6+2 (8) Pin (45cm + 15cm)
2x Molex 4 Pin (50molex +15sata +15sata)
5x S-ATA (50molex +15sata +15sata +15sata)

DC-Output:
+12V SINGLE RAIL : nominal 36A (peak 48A) for MB + GPU like AMD Radeon RX5700
+5V : 13A (peak 18A)
+3.3V : 13A (peak 18A)
-12V : 0.3A (peak 0.3A)
+5Vsb : 2.0A (peak 2.5A)

==================================================================
Proizvodac: Gembird – Scorpion Series
Model: GMB-600 PRO
Snaga: 600V 80+ BROZA, CE / TuV / ROHS
Format: ATX V2.31 i EPS
– Aktivni PFC
– Energetska efikasnost 80+ BROZA: 82%, 85%, 82% pri 20%, 50%, 100% opterec´enja
– Ventilator sa kuglicnim ležajem crvene boje od 12cm, za performanse sa niskom bukom. MTBF: 100.000h
– Zaštita: OVP / UVP / OPP / SCP (Zaštita od prenapona, Podnaponska zaštita, Zaštita od prekomerne struje, zaštita od kratkog spoja)
– 100% izgaranje / vibracije / Hi Pot / Test curenja struje.
– Pakovanje sadrži EU kabl za napajanje od 1,2m
– Ulazna uticnica + I / O
– Prekidac za ukljucivanje / iskljucivanje
– Dužina kabla: sve > 50cm.
Dimenzije: 150x140x85mm

– Konektori, kablovi sa CRNIM MREŽAMA:
1x MB ATX 12V 20+4 Pin (50cm)
1x CPU ATX12V 4+4 Pin (55cm)
2x PCI-E 6+2 (8) Pin (45cm + 15cm)
2x Molex 4 Pin (50molex +15sata +15sata)
5x S-ATA (50molex +15sata +15sata +15sata)

DC-izlaz:
+ 12V SINGLE RAIL: nominalno 36A (maksimum 48A) za MB + GPU poput AMD Radeon RX5700
+ 5V: 13A (maksimum 18A)
+ 3.3V: 13A (maksimum 18A)
-12V: 0,3A (maksimum 0,3A)
+ 5Vsb: 2.0A (maksimum 2.5A)
